DDR4
Non-ECC Unbuffered Memory
DDR4 Wide Temp. UDIMM
Features
- Fully tested and optimized for stability and performance
- Uses original IC to meet strict industrial standards
- Anti-sulfuration protection against harsh environments
- JEDEC standard 1.2V (1.26V ~ 1.14V)
- Operating Environment: -40°C ~ 95°C (Tc)
- 30μ” Gold Finger
- RoHS Compliance
- CE / FCC Certification
DDR4 Wide Temperature UDIMM offers the industry's fastest memory speed with 3200MT/s - the perfect fit for any in-vehicle, surveillance, automation and embedded application. The modules comply with all relevant JEDEC standards, can operate in temperatures from -40ºC to 95°C (Tc), and are available in 4GB, 8GB, 16GB, and 32GB capacities. 2133MT/s, 2400MT/s, 2666MT/s, and 2933 MT/s modules are also available.
SAFEGUARDING MODULES WITH ANTI-SULFURATION PROTECTIVE LAYER
Sulfur is pervasive in many industries. When silver alloys in the DRAM chip encounters sulfur gasses a corrosion reaction occurs. This sulfuration causes lower conductivity and can quickly lead to product failure. To avoid this, Innodisk adds a protective layer above the vulnerable parts to safeguard the silver alloys.
PROVEN RELIABILITY THROUGH 3rd PARTY TESTING
Innodisk’s products are rigorously tested to ensure unmatched reliability and performance in demanding environments. They undergo extensive validation under extreme conditions, adhering to industry standards.
| Bending Test: | Deflection 1.2 mm, EIAJ-4702 |
| DRAM Module Insert & Extract Test: | 100 Cycles, EIA-364-9 |
| Package Drop Test: | Drop Height 76 cm, ISTA-1A |
| Thermal Shock: | -40°C ~ 110°C, 500 Cycles |
| Military Standard Vibration Test: | Vibration Frequency 10 Hz ~ 500 Hz MIL-STD-810G 514.7 |
| Anti-sulfuration Test: | 480 Hours, ASTM B809-95 |
TAILORED TO YOUR SPECIFIC NEEDS
SIDE FILL
Side Fill reinforces the connection between chips and the board, providing superior protection in environments with high vibration or mechanical stress.
CONFORMAL COATING
Conformal Coating applies a protective acrylic layer over the DRAM PCB, shielding it from harmful elements such as moisture, dust, and corrosive substances.
IMPLEMENTED WITH SUCCESS IN DYNAMIC ENVIRONMENTS
TRANSPORTATION
Our solutions enhance operations, management, and security for EVs, buses, subways, and more.
INDUSTRIAL / EMBEDDED
Designed for harsh environments, our products offer high durability to meet the demands of industrial automation and embedded systems.
AUTOMATION
Enhancing efficiency in automated systems, our products provide precise data management and long-lasting performance in industrial applications.
规格表
| Model Name | DDR4 Wide Temperature UDIMM |
|---|---|
| DDR Generation | DDR4 Memory |
| DIMM Type | UDIMM |
| Speed | 2133 MT/s, 2400 MT/s, 2666 MT/s, 2933 MT/s, 3200 MT/s |
| Density | 4GB, 8GB, 16GB, 32GB |
| Function | Non-ECC Unbuffered Memory |
| Pin Number | 288pin |
| Bus Width | x64 |
| Voltage | 1.2V |
| PCB Height | 1.23 Inches |
| Operating Temperature | -40°C ~ 95°C (Tc) |
| 30μ” Gold Finger | Y |
| Anti-Sulfuration | Y |
产品料号
P/N | IC Config. | Rank | Temp. | Description |
M4U0-2GSV15EM | 256M x 16 | 1R x 16 | -40°C ~ 95°C (Tc) | DDR4 3200 2GB Wide Temperature UDIMM |
M4U0-4GSV25EM | 256M x 16 | 2R x 16 | -40°C ~ 95°C (Tc) | DDR4 3200 4GB Wide Temperature UDIMM |
M4U0-4GSSJ5EM | 512M x 8 | 1R x 8 | -40°C ~ 95°C (Tc) | DDR4 3200 4GB Wide Temperature UDIMM |
M4U0-4GSX15EM | 512M x 16 | 1R x 16 | -40°C ~ 95°C (Tc) | DDR4 3200 4GB Wide Temperature UDIMM |
M4U0-4GMX15EM | 512M x 16 | 1R x 16 | -40°C ~ 95°C (Tc) | DDR4 3200 4GB Wide Temperature UDIMM |
M4U0-8GSX25EM | 512M x 16 | 2R x 16 | -40°C ~ 95°C (Tc) | DDR4 3200 8GB Wide Temperature UDIMM |
M4U0-8GSSK5EM | 512M x 8 | 2R x 8 | -40°C ~ 95°C (Tc) | DDR4 3200 8GB Wide Temperature UDIMM |
M4U0-8GS1J5EM | 1G x 8 | 1R x 8 | -40°C ~ 95°C (Tc) | DDR4 3200 8GB Wide Temperature UDIMM |
M4U0-8GM1J5EM | 1G x 8 | 1R x 8 | -40°C ~ 95°C (Tc) | DDR4 3200 8GB Wide Temperature UDIMM |
M4U0-8GSY15EM | 1G x 16 | 1R x 16 | -40°C ~ 95°C (Tc) | DDR4 3200 8GB Wide Temperature UDIMM |
M4U0-AGSY25EM | 1G x 16 | 2R x 16 | -40°C ~ 95°C (Tc) | DDR4 3200 16GB Wide Temperature UDIMM |
M4U0-AGS1K5EM | 1G x 8 | 2R x 8 | -40°C ~ 95°C (Tc) | DDR4 3200 16GB Wide Temperature UDIMM |
M4U0-AGM1K5EM | 1G x 8 | 2R x 8 | -40°C ~ 95°C (Tc) | DDR4 3200 16GB Wide Temperature UDIMM |
M4U0-AGM2J5EM | 2G x 8 | 1R x 8 | -40°C ~ 95°C (Tc) | DDR4 3200 16GB Wide Temperature UDIMM |
M4U0-BGS2K5EM | 2G x 8 | 2R x 8 | -40°C ~ 95°C (Tc) | DDR4 3200 32GB Wide Temperature UDIMM |
M4U0-BGM2K5EM | 2G x 8 | 2R x 8 | -40°C ~ 95°C (Tc) | DDR4 3200 32GB Wide Temperature UDIMM |
*Please contact Innodisk for products with other speeds.
